Elo 2202L Touchscreen Monitor, 22-Inch Wide LCD Desktop, Full HD, Projected Capacitive 10-Touch, USB Controller
Product Codes: E351600, E126096, E159758, E992622
The Elo 2202L Touchscreen Monitor designed with seamless style across all sizes includes four options a 19-inch square aspect ratio display and 22, 24 and 27-inch wide aspect ratio displays. With a compact form factor and clean design for easy integration, the 02-Series monitors are well-suited for point-of-sale, point of information, signage and hospitality applications. And with a variety of peripherals, the monitors can be transformed to meet the demands of your blueprint.
- Description
- Additional information
- SPECIFICATIONS
- Download
Description
Elo 2202L Touchscreen Monitor, 22-Inch Wide LCD Desktop, Full HD, Projected Capacitive 10-Touch, USB Controller, Clear, Zero-bezel, VGA and HDMI Video Interface
Product Codes: E351600, E126096, E159758, E992622
2202L Touchscreen Monitor
The Elo 02-Series of Touchscreen Monitors designed with seamless style across all sizes includes four options ? a 19-inch square aspect ratio display and 22, 24 and 27-inch wide aspect ratio displays. With a compact form factor and clean design for easy integration, the 02-Series monitors are well-suited for point-of-sale, point of information, signage and hospitality applications. And with a variety of peripherals, the monitors can be transformed to meet the demands of your blueprint.
Brilliant Displays from 19 to 27-inches
The brilliant touchscreens with Elo’s industry-leading TouchPro? PCAP technology offer wide viewing angles with impeccable image clarity, resolution, and light transmission for accurate touch response and vivid images. With up to 10 touches enabled, the 02-Series Monitors, provide a tablet-like experience.
POS ready.
The 2002L offers optional accessories with easy installation including: a mag stripe reader (MSR), barcode reader, fingerprint scanner, customer-facing display and near-field communication (NFC/RFID) adapter for mobile payments and increased compatibility with the latest point of sale applications.
Well-Suited for?
Not all businesses have the same needs. Whether you need a touchscreen at the point of sale to process a transaction or in a restaurant to enable self-service for guests to view your menu and submit their order, the line of 02-Series monitors can support the installation needs with ease while maintaining a modern, sleek aesthetic.
Elo Edge Connect? Lets You do More!
Built with versatility in mind, the Elo Edge Connect system offers a wide assortment of peripheral options. Whether for endless aisle, self-order or collaboration applications, you can seamlessly attach any combination of up to four peripherals to the edge of the touchscreen creating a bespoke solution. And, you can add or move them later as your needs change!
One for You. One for Your Customers.
Offer your customers a point of interaction by adding a touchscreen for them to review their transactions, participate in loyalty programs or see the latest promotion.
Mount with Flexibility
Customers demand a seamless shopping experience from first step into the store through check-out. From the stands that come with the monitors to pole mounts, shelf mounts, wall mounts and 3rd party VESA mounts, the touchscreens can be integrated with ease.
Built-to-Last
The 02-Series Touchscreen Monitors deliver the quality and reliability Elo is known for and are backed by our 3-year standard warranty with an optional extension to 5-years. We design, build and are responsible for the complete solution,with touch integrated from the start.
Additional information
| Options | E351600 – 2202L 22" Touchscreen Monitor [Mfr Part # E351600], 2202L – Projected Capacitive, USB, Black, no stand [Mfr Part # E126096], Anti-glare with Stand – E159758, Anti-glare without Stand – E992622 |
|---|
Part Number(s):With Stand – E351600 ; Without Stand – E126096
Enclosure Color: Black
Touch Technology & Capacity: PCAP (Projected Capacitive) – 10 Touch
Diagonal Size:? 21.5” diagonal, Active matrix TFT LCD (LED)
Monitor Thickness: 1.28″ / 32.4 mm panel depth
Aspect Ratio: 16:9
Active Area (mm):? 18.74″ x 10.54″ / 476.06 mm x 267.79 mm
Resolution: 1920 x 1080 @ 50, 60Hz
Other Supported Resolutions:
640 x 480 60Hz
640 x 400 70Hz
720 x 400 70Hz
800 x 500 60Hz
800 x 600 56Hz, 60Hz
1024 x 768 60Hz
1280 x 720 @ 58Hz, 60Hz
1280 x 800 60Hz
1280 x 1024 60Hz
1366 x 768 60Hz, 60Hz RB
1440 x 900 60Hz, 60Hz RB
1680 x 1050 60Hz, 60Hz RB
Viewing Angle: Horizontal: ?89? or 178? total / Vertical: ?89? or 178? total
Number of Colors:16.7 million
Brightness (typical): LCD Panel: 250 nits / PCAP: 225 nits
Response Time-total (typical): 14 msec
Contrast Ratio: 1000:1
Touch Interface: USB
Surface Treatment: Clear
On Screen Display:
Accessible through switches along the bottom:
Controls: Menu, Up, Down, Select
Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Aspect Ratio, Sharpness, Color Temperature, OSD Timeout, OSD Language, Volume, Mute, Recall Defaults, Audio Select, Power LED ON/OFF, Touch Thru
Languages: English, French, Italian, German, Spanish, Japanese, Traditional Chinese, Simplified Chinese, Russian, Korean
Lockouts: OSD, Power
I/O Ports:
VGA
HDMI
Combo Jack
DC jack
USB Type B
USB 2.0 Type A
4x Micro USB
Speakers: Two x 2W internal speakers
Input Video Format:? VGA (VGA DE-15 (DB-15) Male connecter cable included) ; HDMI (HDMI cable included)
Input Video Frequency: Horizontal: 30 ? 82KHz ; Vertical: 50 – 75Hz
Power Consumption (Typical):?
Monitor + AC/DC adapter
ON (Default – 80% Brightness): 14.38 W
ON (Typical – 100% Brightness): 16.26 W
SLEEP: 0.69 W
OFF: 0.32 W
Input Voltage: 12VDC +/- 5% ; 100-240VAC, 50/60Hz
Input Connector: Coaxial power jack (2.1 mm pin outer diameter, 6.4mm barrel inner diameter)
Peripheral Mounting: 4x Micro USB side ports (Top, Bottom, Left, Right)
Monitor Dimensions (without Stand): 12.87″ x 20.74″ x 1.68″ / 326.9 mm x 526.9 mm x 42.7 mm
Monitor Dimensions (with Stand): 15.11″ x 20.74″ x 7.61″ / 383.8 mm x 526.9 mm x 193.4 mm
Shipping Box Dimensions: With Stand: 18.78″ x 24.29″ x 10.24″ / 477 mm x 617 mm x 260 mm ; Without Stand: 17.72″ x 24.92″ x 7.72″ / 450 mm x 633 mm x 196 mm
Weight (Unpackaged): With Stand: 14.88 lbs / 6.75 kg ; Without Stand: 10.47 lbs / 4.75 kg
Weight (Packaged): With Stand: 23.81 lbs / 10.8 kg ; Without Stand: 15.87 lbs / 7.2 kg
Operating Temperature: 0?C to 40?C / 32?F to 104?F
Storage Temperature: -20?C to 60?C / -4?F to 140?F
Humidity: Operating: 20% to 80%; Storage: 10% to 95% (38.7? max wet bulb temperature)
Sealability: Touchscreen sealed to bezel; Touchscreen sealed to LCD
MTBF:?50,000 hours demonstrated
Mounting Options: VESA 4-hole 100mm mounting interface on rear of unit
Warranty: 3-year
Extended Warranty Options:
4 year warranty coverage – Elo P/N: E898247
5 year warranty coverage – Elo P/N: E898449
3 year warranty coverage + AUR – Elo P/N: E898648
4 year warranty coverage + AUR – Elo P/N: E894921
5 year warranty coverage + AUR – Elo P/N: E895125
Regulatory approvals and declarations:
Canada CUL, IC
China CCC
Europe CE
Korea KCC
Taiwan BSMI
United States FCC, UL
Japan VCCI
International CB
Australia RCM
Russia EAC
Mexico CoC
India BIS
RoHS, China RoHS, WEEE, REACH
Ingress Protection: IPX1 – Front only
Impact Protection: IK06
Power Cables:
North America Power Cable C13 – Elo P/N: E593865
Australia Power Cable C13 – Elo P/N: E594067
Europe Power Cable C13 – Elo P/N: E594264
Korea Power Cable C13 – Elo P/N: E594466
China Power Cable C13 – Elo P/N: E594670
Taiwan Power Cable C13 – Elo P/N: E594869
Japan Power Cable C13 – Elo P/N: E793799
What’s in the Box:
Touchmonitor
Quick Install Guide
3x Tie wraps
VGA cable
HDMI cable
Touch USB cable
Audio cable
Power brick
NA Power cable
EU Power cable
EEI Label
4 screws (for E126096)
Replacement DC Power Supply: Power Brick 50W – E593661
Optional Peripherals:
Magnetic Stripe Reader (MSR) ? Elo P/N: E001002
Fingerprint Scanner ? Elo P/N: E134286
2D Barcode Scanner ? Elo P/N: E926356
PCAP Stylus Pen – Elo P/N: E066148
Elo Monitor Handles ? 1 Set – Elo P/N: E352196
EMV Cradle for MagTek eDynamo – Elo P/N: E375343
EMV Cradle for Ingenico RP457c (with Audio Jack, BT and USB) – Elo P/N: E586981
EMV Cradle for Ingenico RP457c (with BT and USB) – Elo P/N: E710930
Temperature Sensor Pro ? Elo P/N: E534879
Stands, Mounts & Kits:?
Wall Mount Kit (75mm or 100mm VESA) ? Elo P/N: E143088
Elo Backpack? – Elo P/N: E611864
Elo Backpack? 3.0 – Elo P/N: E901355
Shelf Mount Bracket (75mm or 100mm VESA) – Elo P/N: E043382
Pole Mount Bracket (75mm or 100mm VESA) – Elo P/N: E045151
1.8m Cable Kit – Elo P/N: E408193
Elo Stand 1902/3-2202/3 – Black – Elo P/N: E804330
Slim Self-Service Countertop Stand (75mm or 100mm VESA) – Elo P/N: E514693
Slim Self-Service Floor Stand (75mm or 100mm VESA) – Elo P/N: E514881 + E515260
