Elo 3263L Open Frame Touchscreen

0 out of 5

Product Codes: E343872, E343671

FEATURES:

  • Elo’s TouchPro® PCAP technology utilizes clear glass with anti-friction coating to provide a smooth experience without surface tension
  • Flexible mounting in portrait, landscape and table-top orientation
  • Enable Smarter Kiosks – Pair your open frame with the Elo Backpack® and EloView® to create an affordable, scalable, single-architecture deployment
Clear

Description

Elo 3263L 32-inch Full HD Open-Frame

Elo’s 3263L 32-inch full HD open-frame delivers a state-of-the-art slim form factor designed for easy integration into enclosures and kiosks. Whether for self-order and self-checkout kiosks or industrial controls, operating room control boards and wayfinding solutions, Elo?s commercial-grade interactive displays offer the versatility to add touch to your solution.

Get the durability your kiosks need.

– UL60950
– IK07
– Ready for 24/7 Use
– IP65 (requires integration)

Brilliant, interactive TouchPro? PCAP display.

The 3263L offers anti-glare or anti-friction models with edge-to-edge glass and up to 40 simultaneous touches for an enhanced, tablet-like experience.

Integrated connectivity.

– HDMI
– USB 2.0
– VGA
– RJ45

Captivate customers and employees with reliable, easy to use interactive solutions.

Designed for easy integration.

Mount the 3263L touchscreen monitor in landscape, portrait and upward facing orientations, providing optimal flexibility for integrating in any counter, kiosk or cabinet design.

Get the viewing experience you want to see.

Whether viewing straight on or at an angle, close-up or from a distance, Elo?s touchscreen displays offer optimal clarity for the viewing experience.

Place your touchscreen behind an extra layer of protection.

For installations that require specific IP ratings or protection from vandalism and harsh environments, Elo?s TouchPro PCAP displays offer touch thru capability. With touch thru technology, the display can be mounted behind a front layer of glass up to 6 mm or plastic up to 3 mm to create a fully enclosed kiosk.

Make your digital transformation faster, and more affordable.

Elo EssentialEdge? for Android offers everything you need to build and operate interactive solutions for your business.

The Elo Backpack brings computing power that scales.

With the Elo Backpack you get a powerful, commercial-grade Android compute engine purpose-built to fit in compact spaces. Boasting a small footprint in both size and weight, the Elo Backpack can secure inside any kiosk with the built-in VESA mount. Scaling Elo?s commercial Android platform across sizes and form factors has never been easier.

EloCare provides service and support from the people who know your Elo products best.

– Advanced Unit Replacement
– Extended Warranty
– Professional Services





Download Elo 3263L Datasheet (265 KB)

Additional information

Options

3263L Open Frame Monitor – TouchPro PCAP (Anti-glare), 3263L Open Frame Monitor – TouchPro PCAP (Clear w/ Anti-friction)

Part Number(s):
TouchPro PCAP (clear with anti-friction) – E343671
TouchPro PCAP (anti-glare) – E343872

Enclosure Color: Black

Touch Technology & Capacity: PCAP (TouchPro? Projected Capacitive) – 40 Touch with Palm Rejection and Touch Thru capability

Touch Thru: Supports up to 6mm glass/3mm plastic with up to 2 touches. Supports gloves up to 1.4mm

Touch Interface: USB

Diagonal Size: 31.5” diagonal, Active matrix TFT LCD (LED)

On Screen Display:

Accessible through switches on the OSD Control Remote accessory.

Controls (side): Menu, Up, Down, Select

Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Aspect Ratio, Sharpness, Color Temperature, OSD Timeout, OSD Language, Recall Defaults, Video Source, Touch, RTC, MDC, Touch Through

Languages: English, French, Italian, German, Spanish, Simplified Chinese, Traditional Chinese, Japanese

Lockouts: OSD, Power

RTC Settings: The clock/time and the monitor ON/OFF schedule can be changed within this menu. Daylight Saving time is adjusted for automatically and will change the current time by one hour to accommodate daylight savings time.

See user manual for full details.

Aspect Ratio: 16:9

Active Area (mm): 27.5″ x 15.47″ / 698.4 mm x 392.9 mm

Resolution: 1920 x 1080 @ 60hz

Other Supported Resolutions:
640×480 @ 60Hz
800×600 @ 56/60Hz
1024×768 @ 60Hz
1280×720 @ 60Hz
1280×800 @ 60Hz RB
1280×960 @ 60Hz
1280×1024 @ 60Hz
1366×768 @ 60Hz
1366×768 @ 60Hz RB
1440×900 @ 60Hz
1440×900 @ 60Hz RB
1680×1050 @ 60Hz
1680×1050 @ 60Hz RB
1920×1080 @ 60Hz

Viewing Angle: Horizontal: Horizontal: ?89? or 178? total / Vertical: ?89? or 178? total

Number of Colors: 8-bit (16.7 million)

Brightness (typical):
LCD panel: 500 nits
TouchPro PCAP: 425 nits

Response Time-total (typical): 8 msec

I/O Ports:
HDMI 1.4 x2
USB 2.0 Type B (for Touch)
RJ45 (for optional OSD remote)
VGA

Video:
2x HDCP-capable HDMI on Type A connector
Female DE-15 VGA connector
Input Video Horizontal Sync frequency range: 31.5 ? 80 KHz
Input Video Vertical Sync (frame rate) frequency range: 47 ? 63 KHz

Power:
Input connector (power): IEC 60320-C14
Input signal specifications (power): 100-240VAC 50/60Hz

Maximum Operating Time: 24 hours/day

Power Consumption (Typical):
ON (monitor + AC/DC adapter): 44.3 W
SLEEP (monitor + AC/DC adapter): 0.61 W
OFF (monitor + AC/DC adapter): 0.20 W

Dimensions: 29.42″ x 17.82″ x 2.16″ / 747.3 mm x 452.7 mm x 55 mm

Shipping Box Dimensions: 39.4″ x 12.05″ x 26.79″ / 1000 mm x 306 mm x 680 mm

Weight (Unpackaged): 24.17 lbs / 10.99 Kg

Weight (Packaged): 37.47 lbs / 17.03 Kg

Operating Temperature:

Portrait/Landscape Mode: 0?C to 40?C / 32?F to 104?F
Tabletop Mode: 0? C to 35? C / 32?F to 95?F

Storage Temperature:

Portrait/Landscape Mode: -20?C to 60?C / -4?F to 140?F
Tabletop Mode: -20? C to 60? C / -4? F to 140? F

Humidity:?

Operating: 20% to 80%
Storage: 10% to 90% (38.7?C max wet bulb temperature)

Sealability:

Touchscreen sealed to bezel
Touchscreen sealed to LCD

MTBF: 50,000 hours demonstrated

Warranty: 3-year

Extended Warranty Options:
4 year warranty coverage + AUR – Elo P/N: E740135
5 year warranty coverage + AUR – Elo P/N: E740330

Regulatory approvals and declarations:
Argentina S-Mark
Australia RCM
Canada CUL, IC
China CCC
Europe CE
Japan VCCI
Korea KCC e-Standby
Mexico CoC
Russia EAC
Taiwan BSMI
United States UL, FCC
International CB
Mexico NOM
RoHS, China RoHS, WEEE
Energy Star 8.0
UL 60950 ball-drop compliant
IK07 impact compliant
CB (International safety) (IEC/EN60950-1+IEC/EN62368-1)

Mounting Options:

VESA 400mm x 200mm
See dimensional drawings for details

Other Features: Ambient Light Sensor – changes panel color to match ambient light, Auto Wake

What’s in the Box:
Quick Install Guide
HDMI 1.4 cable (Type A plug to Type A plug)
VGA cable (DB-15 male to DB-15 male)
USB cable (Type A plug to Type B plug)
RJ45 Wired OSD remote
Power cable, IEC 60320-C13 to NA plug
Power cable, IEC 60320-C13 to EU/KR plug
Power cable, IEC 60320-C13 to UK plug
Energy label according to EU Regulation 2019/2013
8 sets Flushmount Brackets 48 pcs Screws

Options / Peripherals / Upgrades:
Elo Remote OSD (RJ45) – Elo P/N: E483757
Optional PCAP Stylus Pen – Elo P/N: E066148
Elo Backpack? 4 (Value Model)- Elo P/N: E393754
Elo Backpack? 4 (Standard Model) – Elo P/N: E393359
