Elo 1004L 10 Inch Anti-glare Touchscreen Monitor
Product Code: E968703, E315290
A durable and compact 10.1″ touchscreen ideal for retail, kiosks, and industrial applications.
Features:
-
10.1″ HD PCAP touchscreen
-
USB-C, HDMI, DisplayPort
-
Anti-glare, optical bonding
-
IP54 & IK07 rated
-
Elo Edge Connect™ accessory support
- Description
- Additional information
- Reviews (0)
- Download
Description
Elo 1004L 10 Inch Anti-glare Touchscreen Monitor
Product Code: E968703, E315290
The Elo 1004L is a slick, rugged, and flexible 10″ touchscreen designed for demanding environments—perfect for POS, kiosks, industrial panels, and more. Optical bonding, full payment accessory support, and thoughtful features like secure cabling make it a strong candidate for commercial deployments.
Key Highlights
- Commercial-grade, 10.1″ (1280×800) PCAP touchscreen, supporting up to 10 simultaneous touches with vibrant 16.7M color output.
- Optical bonding + anti‑glare cover glass + low‑blue‑light mode, designed for enhanced viewing comfort and readability.
- Durability features: IP54 protection, IK07-rated impact resistance, scratch-resistant glass, 50,000 hour MTBF.
- Secure cable management: Captive port covers prevent accidental disconnections.
- Elo Edge Connect™ support: Easily integrate accessories like EMV readers, barcode scanners, cameras, RFID antennas, status lights, MSR, fingerprint scanners.
- OSD navigation via touchscreen with lock security, plus settings for brightness, contrast, color temperature, low blue light, and peripheral port control.
Connectivity & Mounting
- Extensive connectivity: USB‑C (power, video, touch), HDMI, DisplayPort, micro-USB, DC jack, plus 4× Edge‑Connect ports. Includes dual integrated 2 W speakers.
- Supports flush, desktop, wall, and pole mounting with VESA-compatible 75 mm adapters.
Applications & Use Cases
Ideal for environments and uses such as:
-
Point-of-sale stacks (pair nicely with Elo Pay 7″ or mobile POS)
-
Self-service kiosks
-
Kitchen display terminals
-
Warehouse automation interfaces
-
Access control systems
-
Industrial HMI screens
Additional information
Options | Elo 1004L, Projected Capacitive 10-touchscreen, USB Controller, USB-C, HDMI and DP Inputs, Black (E968703), Elo 1004L, Non-touch Monitor, No Stand, USB-C, HDMI and DP Inputs (E315290) |
---|
