QD CUSTOMER DISPLAY Backlit graphic LCD display
- Description
- Reviews (0)
- Download
- Technical sheet
Description
Newly designed CUSTOM QD graphic display with updated features. It features an innovative design and new construction materials, and has been specially conceived to be used in combination with the all Custom family printers. The graphic LCD technology allows you to create phrases, messages and drawings on the display. The tower case can be telescopically adjusted and allows it to be positioned at the best height for operator and customer reading. Backlit graphic LCD display specially designed for ECR and POS systems. It is equipped with serial RS232 interface. The display is powered directly by the CUSTOM printer (as optional, it may be equipped with serial cable and power adapter for direct connection to the PC).
Be the first to review “QD CUSTOMER DISPLAY Backlit graphic LCD display”
| Display method | Backlit liquid crystal display |
|---|---|
| Number of characters | 40 (20 columns x 2 lines) |
| Background colour | Blue |
| Character set | 96 alphanumeric; 12 international |
| Character font | 5 x 9 dot matrix |
| Character size | 3.25mm x 5.85mm |
| Character pitch | 3.90 mm x 5.85 mm |
| Space between characters | 0.65 mm |
| Space between rows | 4 mm |
| Emulation | ESC/POS, CD5220 |
| Viewing angle | 8-35° |
| Rotation angle | -60°, +60° (2 directions) |
| Interfaces | Serial RS232 |
| Power supply | 11÷ 26 Vdc ± 10% |
| Medium consumption | 20 mA (working) |
